Bevel iav Pinion

Bevel iav pinion:

SST machinery bevel iav pinion yog lub khob hliav qab nrog rau sab nraud involute radial hniav uas ncaj, tapering los ntawm loj mus rau me me.

Qhov loj kawg ntawm bevel pinion yog hauv qab; qhov kawg me me ntawm bevel pinion yog sab saum toj.

Lub suab ntawm bevel yog ntsuas nyob rau hauv qab (cov hniav loj tshaj plaws).

Lub sij hawm bevel pinion los yog bevel iav hais txog ib qho ncaj (los yog spur) bevel. Nws yog tiag tiag tapered spur iav.

Bevel iav kuj tseem siv tau rau kev hloov pauv kev hloov pauv ntawm lub zog xa hluav taws xob uas hu ua miter gears.

Rau miter gears, input thiab output bevel gears muaj tib tus lej ntawm cov hniav.

M1, M2, M3, M4, M5, M6, M7, M8, PIB 4, PITCH, 6, PIB 8, PICTH 10, PICTH 12

Tus yam ntxwv ntawm bevel iav kis tau tus mob yog txo cov hniav sab saum toj qhov siab ntawm qhov me me kawg ntawm cov iav hniav, yog li txo qhov muaj peev xwm ntawm cov hniav saum toj kawg nkaus; Lub vojvoog loj dua ntawm cov hauv paus hniav yog qhov tsim nyog rau kev txhim kho cov kabmob muaj peev xwm ntawm cov hniav iav, cov cuab yeej lub neej thiab cov roj cia lubrication. Nws yog feem ntau siv nyob rau hauv lub teeb load thiab tsawg ceev xwm txheej.

Nyob rau hauv dav dav machinery, qhov kev sib tshuam lub kaum sab xis ntawm ob shafts ntawm bevel iav pinion yog sib npaug zos rau 90 degree (tab sis nws kuj yuav txawv). Zoo li cylindrical zog, bevel iav muaj indexing cones, addendum cones, cag cones, thiab puag cones. Lub khob hliav qab muaj qhov kawg loj thiab qhov kawg me me, thiab cov voj voog sib txuas mus rau qhov loj kawg yog hu ua lub voj voog sib faib (nws lub vojvoog yog r), lub voj voog ntxiv, lub voj voog hauv paus thiab lub voj voog raws li. Cov lus tsa suab ntawm ib khub ntawm bevel iav yog sib npaug rau cov ntshiab dov ntawm ib khub ntawm lub suab cones.

Kev tsim cov hniav profile ntawm bevel iav pinion zoo ib yam li cov iav cylindrical, tab sis qhov txawv yog tias lub hauv paus lub khob hliav qab yog siv los ntawm lub hauv paus lub tog raj kheej. Raws li pom nyob rau hauv daim duab yog, lub generating nto S yog tangent rau lub hauv paus cone tsheb npav. Thaum lub generating nto S rolls purely raws lub hauv paus lub khob hliav qab, ib tug involute nto yuav tsim nyob rau hauv qhov chaw los ntawm ib tug ncaj kab OK ntawm lub generating nto uas hu rau lub generatrix ON ntawm lub hauv paus lub khob hliav qab. Qhov saum npoo no yog tus hniav profile nto ntawm cov iav ncaj bevel. Qhov chaw ntawm txhua qhov taw tes ntawm txoj kab ncaj nraim OK yog ib qho involute (lub involute ntawm lub vertex O yog ib qho point).
