Kauv Bevel Gears

Spiral bevel iav:

SSTmachinery ua zoo zoo bevel iav teeb.

Tag nrho cov kauv bevel iav ua los ntawm CNC tshuab dhos thiab tswj kom zoo rau qhov loj me.

Kauv bevel iav yog ib lub iav nrog ib tug truncated cone profile thiab helical los yog nkhaus hniav.

Bevel iav feem ntau yog siv qhov kev taw qhia ntawm lub tswv yim tsav yuav tsum tig 90 degrees.

Qhov piv txwv feem ntau ntawm kev siv bevel iav kom ua tiav qhov kev hloov pauv 90 degree no yog qhov sib txawv ntawm lub tsheb.

Lub iav bevel iav nta helical los yog nkhaus hniav vim hais tias tus hniav tsim no ua rau tsis tshua muaj kev vibration thiab suab nrov thiab muaj peev xwm tiv taus kev sib hloov ceev dua spur los yog ncaj txiav hniav.

Kauv bevel iav raug txiav nrog sab xis lossis sab laug tes taw kev taw qhia nrog lawv cov pinion sib xws lossis cov iav uas tau tsav los ntawm kev taw qhia tawm.

Vim muaj kev sib cuam tshuam ntawm cov hniav, helical iav ua haujlwm zoo dua thiab ntsiag to dua li cov iav spur. Cov hniav ntawm lub helical iav yog txiav ntawm lub kaum sab xis nrog lub iav nto. Thaum ob lub hniav pib sib txuas, kev sib cuag yog maj mam, pib ntawm ib kawg ntawm cov hniav thiab tuav kev sib cuag raws li lub iav tig mus rau tag nrho cov kev koom tes. Lub kaum sab xis feem ntau yog kwv yees li 15-30 degrees. Lub thrust load hloov ncaj qha nrog lub tangent ntawm lub helix lub kaum sab xis, thiab lub helix yog cov iav feem ntau siv hauv kev sib kis. Lawv kuj tsim kom muaj kev sib tw ntau thiab siv cov bearings los pab txhawb nqa thrust loads. Helical iav tuaj yeem siv los kho lub kaum sab xis ntawm kev sib hloov ntawm 90 degrees. Thaum mounted ntawm ib tug ntsug axis. Nws qhov sib kis tau zoo li qub yog 3: 2 txog 10: 1.

Hypoid iav yog ib lub iav helical uas nws cov duab yog ib tug rotating hyperboloid es tsis yog lub khob hliav qab. Hypoid gears tso lub pinion ntawm lub nplhaib iav los yog yas log. Qhov no tso cai rau tus pinion kom muaj txoj kab uas hla loj dua thiab muab ntau qhov chaw sib cuag. Lub pinion thiab iav feem ntau yog qhov sib txawv, thiab lub helix lub kaum sab xis ntawm lub pinion feem ntau yog ntau dua li lub kaum sab xis. Hypoid iav yog siv nyob rau hauv lub zog kis tau tus mob vim nws loj kis tau tus mob piv. Feem ntau, cov iav piv ib txwm yog 10: 1 txog 200: 1.
